| Tickness (mm) | Theoretical Weight (kg/m²) | Thickness (mm) | Theoretical Weight (kg/m²) | Thickness (mm) | Theoretical Weight (kg/m²) |
|---|---|---|---|---|---|
| 0.35 | 2.748 | 6 | 47.10 | 48 | 376.80 |
| 0.50 | 3.925 | 7 | 54.95 | 50 | 392.50 |
| 0.55 | 4.318 | 8 | 62.80 | 52 | 408.20 |
| 0.60 | 4.710 | 9 | 70.65 | 55 | 431.75 |
| 0.65 | 5.103 | 10 | 78.50 | 60 | 471.00 |
| 0.70 | 5.495 | 11 | 86.35 | 65 | 510.25 |
| 0.75 | 5.888 | 12 | 94.20 | 70 | 549.50 |
| 0.80 | 6.280 | 13 | 102.05 | 75 | 588.75 |
| 0.90 | 7.065 | 14 | 109.90 | 80 | 628.00 |
| 1.0 | 7.850 | 15 | 117.75 | 85 | 667.25 |
| 1.2 | 9.420 | 16 | 125.60 | 90 | 706.50 |
| 1.3 | 10.205 | 17 | 133.45 | 95 | 745.75 |
| 1.4 | 10.990 | 18 | 141.30 | 100 | 785.00 |
| 1.5 | 11.775 | 19 | 149.15 | 105 | 824.25 |
| 1.6 | 12.560 | 20 | 157.00 | 110 | 863.50 |
| 1.8 | 14.130 | 21 | 164.85 | 120 | 942.00 |
| 2.0 | 15.700 | 22 | 172.70 | 125 | 981.25 |
| 2.2 | 17.270 | 25 | 196.25 | 130 | 1020.50 |
| 2.5 | 19.625 | 26 | 204.10 | 140 | 1099.00 |
| 2.8 | 21.980 | 28 | 219.80 | 150 | 1177.50 |
| 3.0 | 23.550 | 30 | 235.50 | 160 | 1256.00 |
| 3.2 | 25.120 | 32 | 251.20 | 165 | 1295.25 |
| 3.5 | 27.475 | 34 | 266.90 | 170 | 1334.50 |
| 3.8 | 29.830 | 36 | 282.60 | 180 | 1413.00 |
| 3.9 | 30.615 | 38 | 298.80 | 165 | 1452.25 |
| 4.0 | 31.400 | 40 | 314.00 | 190 | 1491.50 |
| 4.5 | 35.325 | 42 | 329.70 | 195 | 1530.75 |
| 39.25 | 45 | 353.25 | 200 | 1570.00 |
