Equal Angle(JIS)
| Size Leg Length×Leg Length×thickness (mm) | JIS Weight (kg/m) | Available Length | Size Leg Length×Leg Length×thickness (mm) | JIS Weight (kg/m) | Available Length |
|---|---|---|---|---|---|
| 20×20×3 | 0.885 | 6-12m | 80×80×6 | 7.32 | 6-12m |
| 25×25×3 | 1.12 | 6-12m | 80×80×7 | 8.48 | 6-12m |
| 30×30×3 | 1.36 | 6-12m | 80×80×8 | 9.55 | 6-12m |
| 30×30×4 | 1.78 | 6-12m | 90×90×6 | 8.25 | 6-12m |
| 30×30×5 | 2.16 | 6-12m | 90×90×7 | 9.59 | 6-12m |
| 38×38×3 | 1.72 | 6-12m | 90×90×8 | 10.9 | 6-12m |
| 38×38×4 | 2.26 | 6-12m | 90×90×9 | 12.2 | 6-12m |
| 40×40×3 | 1.83 | 6-12m | 90×90×10 | 13.3 | 6-12m |
| 40×40×4 | 2.41 | 6-12m | 100×100×6 | 9.22 | 6-12m |
| 40×40×5 | 2.95 | 6-12m | 100×100×7 | 10.7 | 6-12m |
| 50×50×3 | 2.33 | 6-12m | 100×100×8 | 12.1 | 6-12m |
| 50×50×4 | 3.06 | 6-12m | 100×100×10 | 14.9 | 6-12m |
| 50×50×5 | 3.77 | 6-12m | 120×120×8 | 14.7 | 6-12m |
| 50×50×6 | 4.43 | 6-12m | 120×120×10 | 18.2 | 6-12m |
| 60×60×5 | 4.55 | 6-12m | 120×120×12 | 21.5 | 6-12m |
| 60×60×6 | 5.41 | 6-12m | 130×130×9 | 17.9 | 6-12m |
| 65×65×5 | 5.00 | 6-12m | 130×130×10 | 19.7 | 6-12m |
| 65×65×6 | 5.91 | 6-12m | 130×130×12 | 23.4 | 6-12m |
| 65×65×8 | 7.66 | 6-12m | 150×150×10 | 22.9 | 6-12m |
| 70×70×5 | 5.37 | 6-12m | 150×150×12 | 27.3 | 6-12m |
| 70×70×6 | 6.38 | 6-12m | 150×150×15 | 33.6 | 6-12m |
| 70×70×7 | 7.35 | 6-12m | 200×200×15 | 45.3 | 6-12m |
| 75×75×5 | 5.76 | 6-12m | 200×200×20 | 59.7 | 6-12m |
| 75×75×6 | 6.85 | 6-12m | 200×200×24 | 71.1 | 6-12m |
| 75×75×7 | 7.94 | 6-12m | 250×250×25 | 93.7 | 6-12m |
| 75×75×8 | 8.92 | 6-12m | 250×250×28 | 104 | 6-12m |
| 75×75×9 | 9.96 | 6-12m | 250×250×35 | 128 | 6-12m |
Equal Angle(GB)
| Size Leg Length×Leg Length×thickness (mm) | JIS Weight (kg/m) | Available Length | Size Leg Length×Leg Length×thickness (mm) | JIS Weight (kg/m) | Available Length |
|---|---|---|---|---|---|
| 25×25×3 | 1.124 | 6-12m | 90×90×8 | 10.946 | 6-12m |
| 25×25×4 | 1.459 | 6-12m | 90×90×9 | 12.216 | 6-12m |
| 30×30×3 | 1.373 | 6-12m | 90×90×10 | 13.476 | 6-12m |
| 30×30×4 | 1.786 | 6-12m | 90×90×12 | 15.94 | 6-12m |
| 40×40×3 | 1.852 | 6-12m | 100×100×6 | 9.366 | 6-12m |
| 40×40×4 | 2.422 | 6-12m | 100×100×7 | 10.83 | 6-12m |
| 40×40×5 | 2.976 | 6-12m | 100×100×8 | 12.276 | 6-12m |
| 45×45×3 | 2.088 | 6-12m | 100×100×10 | 15.12 | 6-12m |
| 45×45×4 | 2.736 | 6-12m | 100×100×12 | 17.898 | 6-12m |
| 45×45×5 | 3.369 | 6-12m | 100×100×14 | 20.611 | 6-12m |
| 45×45×6 | 3.985 | 6-12m | 100×100×16 | 23.257 | 6-12m |
| 50×50×3 | 2.332 | 6-12m | 110×110×7 | 11.928 | 6-12m |
| 50×50×4 | 3.059 | 6-12m | 110×110×8 | 13.532 | 6-12m |
| 50×50×5 | 3.770 | 6-12m | 110×110×10 | 16.69 | 6-12m |
| 50×50×6 | 4.465 | 6-12m | 110×110×12 | 19.782 | 6-12m |
| 56×56×3 | 2.624 | 6-12m | 110×110×14 | 22.809 | 6-12m |
| 56×56×4 | 3.446 | 6-12m | 120×120×10 | 18.2 | 6-12m |
| 56×56×5 | 4.251 | 6-12m | 120×120×12 | 21.6 | 6-12m |
| 60×60×5 | 4.57 | 6-12m | 125×125×8 | 15.504 | 6-12m |
| 60×60×6 | 5.42 | 6-12m | 125×125×10 | 19.133 | 6-12m |
| 63×63×4 | 3.907 | 6-12m | 125×125×12 | 22.696 | 6-12m |
| 63×63×5 | 4.822 | 6-12m | 125×125×14 | 26.193 | 6-12m |
| 63×63×6 | 5.721 | 6-12m | 140×140×10 | 21.488 | 6-12m |
| 63×63×8 | 7.469 | 6-12m | 140×140×12 | 25.522 | 6-12m |
| 70×70×5 | 5.397 | 6-12m | 140×140×14 | 29.49 | 6-12m |
| 70×70×6 | 6.406 | 6-12m | 140×140×16 | 33.393 | 6-12m |
| 70×70×7 | 7.398 | 6-12m | 160×160×10 | 24.729 | 6-12m |
| 70×70×8 | 8.373 | 6-12m | 160×160×12 | 29.391 | 6-12m |
| 75×75×5 | 5.818 | 6-12m | 160×160×14 | 33.987 | 6-12m |
| 75×75×6 | 6.905 | 6-12m | 160×160×16 | 38.518 | 6-12m |
| 75×75×7 | 7.976 | 6-12m | 180×180×12 | 33.159 | 6-12m |
| 75×75×8 | 9.03 | 6-12m | 180×180×14 | 38.383 | 6-12m |
| 75×75×10 | 11.089 | 6-12m | 180×180×16 | 43.542 | 6-12m |
| 80×80×5 | 6.211 | 6-12m | 180×180×18 | 48.634 | 6-12m |
| 80×80×6 | 7.376 | 6-12m | 200×200×14 | 42.894 | 6-12m |
| 80×80×7 | 8.525 | 6-12m | 200×200×16 | 48.68 | 6-12m |
| 80×80×8 | 9.658 | 6-12m | 200×200×18 | 54.401 | 6-12m |
| 80×80×10 | 11.874 | 6-12m | 200×200×20 | 60.056 | 6-12m |
| 90×90×6 | 8.35 | 6-12m | 200×200×24 | 71.168 | 6-12m |
| 90×90×7 | 9.656 | 6-12m |
